Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8®

Optimised for Virtualisation and Network Security Appliance. 8x GbE LAN ports, 1x Dedicated IPMI LAN.

  • uCPE Network Appliance
  • Network Security Appliance
  • Virtualization
  • Single Socket H4 (LGA 1151) supports Intel Xeon processor E-2100, 8th Gen. Intel Core™ i3 Processors, Intel Celeron, Intel Pentium
  • Intel C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz; 4 DIMM slots
  • 1 PCI-E 3.0 x16 (FHFL) slot
  • 2 Hot-swap 2.5" SATA3 drive bays, 2 Internal 2.5" SATA3 drive bays (SSD only)
  • M.2 Interface: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4
  • M.2 Form Factor: 2280/22110
  • M.2 Key: M-Key
  • 8 GbE LAN ports, 1 Dedicated IPMI LAN
  • 2 USB 3.1, 2 USB 2.0, 1 VGA
  • 350W AC-DC multiple output Platinum Level Power Supply



Loading Configurator...

Prices for products are subject to change without notice and Prices do not include shipping and/or handling charges or applicable taxes.

3 Years Warranty as Standard

Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.

Up To 50% More Cores

Powered by the latest Intel Xeon E family of processors, featuring up to 50% more cores than previous generation Xeon processors.

Performance Breakthroughs

Powered by the revolutionary Intel Xeon E processor range, delivering massive improvements in every metric over the previous generation processors.

Data Protection Technology

Security is substantially improved with Intel Data Protection Technology (with Advanced Encryption Standard New Instructions).

Ideal For Small Business

Systems based on Intel Xeon E processors enable your business to evolve while also delivering a constantly available solution to safeguard your data.

Configure With Up to 128GB of RAM

Equipable with up to 128GB of RAM, this system optimised for light to mid level processing and offers a superb performance to cost ratio.

Optimised For Virtualisation

Designed to excel at virtualisation. You can use virtual machines for testing, to save physical space, to reduce costs, for hardware for increased compatibility and more.

Configure With Hot-Swap Drives

The Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 features hot-swap hard drives, giving you more flexibility and allowing you to remove drives without having to shut down the system.

Configure with 2.5" Drives

The Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 can be configured with 2.5" drives, a more space efficient and low noise option. These drives also offer energy savings and increased flexibility.

Eight LAN with Intel This server features aI210-AT

The Eight LAN with Intel I210-AT network adapter delivers high performance. This server is completely free from vendor lock-in and features wide ranging hardware and software compatibility.


A 1U Supermicro SuperServer based on 1x Intel Xeon E-2100 range of processors, the Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 is configurable with up to 2x Hot-Swap Drives drive bays, and designed for optimal performance with 4x 2666MHz DDR4 memory sockets .

The Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 supports the Intel Intel Xeon E 2100 Series , Intel Xeon E 2200 Series family in a high-density 1U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

The Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 boasts 1 PCI-Express slots for expandability, and as with all of our servers it can be fully customised online

Supermicro SYS-1019C-FHTN8 SuperServer | 1019C-FHTN8 Specs
  • Brand: Supermicro
  • U Size: 1U
  • Processor Family: Xeon E-2100
  • Range: Virtualisation Supermicro SuperServers
  • High-Density Twin Servers:
  • Drive Bays: Hot-Swap Drives
  • HDD Size: 2.5" Drives
  • Maximum RAM Capacity: 64GB
