| Maximum Core Count Supported |
Up to 40 |
| Base Frequency Supported |
Up to 3.1 GHz |
| Maximum Single-Core Intel Turbo Boost Technology 2.0 Frequency Supported |
Up to 4.3 GHz |
| Processor Cache Memory Support |
Up to 38.5 MB of L3 Cache (1.375 MB/core) |
| Intel Ultra Path Interconnect (Intel UPI) |
Six Intel UPI supported per processor (Up to 10.4 GT/s) |
| Processor Performance Support |
Intel Turbo Boost 2.0 Technology, Intel Hyper-Threading Technology (Intel HT), Intel Speed Shift Technology,
Enhanced Intel SpeedStep Technology |
| Intel Speed Select Technology (Intel SST) |
Intel SST Core Power (SST-CP) and Intel SST Turbo Frequency (SST-TF) features are supported on select
processors |
| Intel Deep Learning Boost |
VNNI and bfloat16 supported |
| Intel Advanced Vector Extension 512 (Intel AVX-512) Support |
Intel AVX-512 with up to 2 FMA support |
| Number of Processor Sockets Supported |
4 or 8 sockets |
| Thermal Design Point (TDP) |
Supporting a range from 150W to 260W depending on customer needs and implementation |
| Socket Type |
Socket P+ (4189 pins) |
| System Memory Support |
6 channels, Up to DDR4 3200 MT/s (1 DPC) with ECC support
12 DIMMs/socket, Support for 16Gb density DIMMs
|
| Intel Optane Persistent Memory Support |
Intel Optane Persistent memory 200 series supported on 4-socket systems only |
| Maximum DRAM System Memory Supported |
Up to 4.5 TB per socket |
| Supported Chipsets |
Intel C620A series chipsets, available with integrated Intel QuickAssist Technology |
| PCH I/O |
PCI Express* 3 - Up to 20 lanes (8 GT/s)
USB* 3.0 - Up to 10 ports
SATA* 3.0 - Up to 14 ports
DMI - Up to 4 lanes, Gen 3 |
| Platform Manageability |
Intel Server Platform Services (Intel SPS) and Intel Resource Director Technology (Intel RDT) |
| Storage Manageability |
Intel Volume Management Device (Intel VMD) |
